1.3MP AHD waterproof car camera with mirror

Image sensor

 1/3 AR0130

Gain control

 Automatic

Format

 NTSC/PAL

Signal-to-noise ratio

 better than 48DB

Effective pixels

 1280 (H) X960 (V)

White balance

 automatic

Pixel size

 6.2UM*7.4UM

GAMMA coefficient

 0.45

Effective image area

 4.623MM*3.611MM

Electronic shutter

 AUTO

Synchronization system

 Internal synchronization

Backlight compensation

 AUTO

Resolution

 1.3 million pixels

Power supply voltage

 DC12V

Microphone

 optional

Lens

 2.3MM

Number of infrared lights

 6PCS Lens angle

 Lens angle

150°

Output signal amplitude

 1.0VP-P/75OHM

Current consumption

 65±5MA

Scanning system

 interlaced scanning

Working environment temperature

 -20C-70℃, maximum humidity 95%

Minimum illumination

 0.1LUX (DAY), 0 LUX (WITH IR)

Storage temperature

 -30C-80℃, maximum humidity 95%
