700TVL Cmos infrared vehicle camera
Image sensor |
1/3 CMOS PC2099K |
Gain control |
automatic |
Resolution |
700 TVL |
Signal-to-noise ratio |
better than 48dB |
Format |
NTSC/PAL |
White balance |
automatic |
Microphone |
optional |
Gamma coefficient |
0.45 |
Quantity of infrared lights |
18PCS |
Electronic shutter |
AUTO |
Output signal amplitude |
1.0Vp-p/75 0hm |
Backlight compensation |
AUTO |
Scanning system |
interlaced scanning |
Power supply voltage |
DC12V |
Effective pixels |
968(H)*488(V) |
Lens |
2.8mm |
Photosensitive area |
4.880mm*3.670mm |
Lens angle |
120° |
Storage temperature |
-30℃-80℃, maximum humidity 95% |
Current consumption |
65±5mA |
Minimum illumination |
0.1 Lux (day), 0 Lux (with IR) |
Synchronization system |
internal synchronization |
Working environment temperature |
-20℃-70℃, maximum humidity 95% |
